Quick coupler
- WQ series (Sizes : 1/4, 1/2)
- Nickel plated brass body
- High flow characteristics
- Wide range of models
- Maintenance free and long life
- Compact size
- Attractive design
- Teflon pre-coated male taper threads
- This can be effectively used in all compressed air line applications – Some of them include
- All compressed air lines
- Assembly lines with pneumatic tools / Machinery with pneumatic systems
- Pneumatic control panels
To connect the coupling, simply push the plug in to the coupling.
To disconnect the coupling, push the sleeve back and the plug automatically comes out.
Safety precautionary note:
During disconnecting under pressure, the plug comes out with high speed and force. Hence care to be taken to prevent injury.
