FRCLM with Internal Autodrain
- FRCLM1A – G3/8, G1/2, G3/4, G1”
- Modular type for easy and fast maintenance
- Suitable for wall mounting
- Filter
- Bronze filtering element
- Separator and shield for efficient moisture separation
- Internal Autodrain
- Float type, no electrical connections required
- Manual drain is also provided / possible
- Provision for drain tube connection, to take the condensate away from the unit, to keep the working area clean
- Regulator
- Diaphragm operated, relieving type
- Pressure compensated by balanced poppet
- Flow compensated (with venturi) for faster response
- Non raising Press to lock adjusting knob for locking at any set pressure
- Lubricator
- Fog / Mist type Lubricator
- Fine adjustment of lubrication
- Lubrication proportional to flow
- Steel bowl guard, bayonet type on FRLM14, FRLM15 & FRLM17 models
- Good flow and regulating characteristics
Pull the knob and adjust by turning the knob clockwise to increase the pressure. Push the knob back to its locked position. ( Turning the knob counter clockwise will reduce the pressure )
